User’s Manual of WGS Managed Series
243
4.9.5.2 SSH
Configure SSH on this Page. This Page shows the Port Security status. Port Security is a module with no direct configuration.
Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port,
the port is set-up for software-based learning. In this mode, frames from unknown MAC addresses are passed on to the port
security module, which in turn asks all user modules whether to allow this new MAC address to forward or block it. For a MAC
address to be set in the forwarding state, all enabled user modules must unanimously agree on allowing the MAC address to
forward. If only one chooses to block it, it will be blocked until that user module decides otherwise.
The SSH Settings and Information screens in Figure 4-9-22 & Figure 4-9-23 appear.
Figure 4-9-22 SSH Settings Page Screenshot
The page includes the following fields:
Object Description
• SSH Service
Disable or enable SSH service
• Login Authentication List
Select login authentication list from this drop-down list
• Enable Authentication List
Select enable authentication list from this drop-down list
• Session Timeout
Set the session timeout value
• Password Retry Count
Set the password retry count value
• Silent Time
Set the silent time value
Buttons
: Click to apply changes.
: Click to disconnect telnet communication.
