User’s Manual of WGS Managed Series
112
The page includes the following fields:
Object Description
• OE-Present
Display the current SFP OE-present
• LOS
Display the current SFP LOS
4.3.10.2 SFP Module Detail Status
The SFP Module Detail Status screen in Figure 4-3-22 appears.
Figure 4-3-22 SFP Module Detail Status Page Screenshot with Sample Switch
The page includes the following fields:
Object Description
• Port
The logical port for the settings contained in the same row
• Temperature
Display the current SFP temperature
• Voltage
Display the current SFP voltage
• Current
Display the current SFP current
• Output Power
Display the current SFP output power
• Input Power
Display the current SFP input power
• Transmit Fault
Display the current SFP transmits fault
• Loss of Signal
Display the current SFP loss of signal.
• Rate Ready
Display the current SFP rate ready.
