User’s Manual of WGS Managed Series
Buttons
: Click to add a new SNMPv3 host entry.
Figure 4-2-34 SNMPv3 Host Status Page Screenshot
The page includes the following fields:
Object Description
• Server Address
Display the current server address
• Notify Type
Display the current notify type
• User Name
Display the current user name
• UDP Port
Display the current UDP port
• Time Out
Display the current time out
• Retries
Display the current retry times
• Action
: Delete the SNMPv3 host entry
4.2.7.9 SNMP Engine ID
Configure SNMPv3 Engine ID on this page. The entry index key is Engine ID. The remote engine ID is used to compute the
security digest for authenticating and encrypting packets sent to a user on the remote host. The SNMPv3 Engine ID Setting
screens in Figure 4-2-35 & Figure 4-2-36 appear.
Figure 4-2-35 SNMPv3 Engine ID Setting Page Screenshot
