User’s Manual of WGS Managed Series
207
Buttons
: Click to apply changes.
Figure 4-8-6 Queue Information Page Screenshot
The page includes the following fields:
Object Description
• Information Name
Display the current queue method information
• Information Value
Display the current queue value information
4.8.2.4 CoS Mapping
The CoS to Queue and Queue to CoS Mapping screens in Figure 4-8-7 & Figure 4-8-8 appear.
Figure 4-8-7 CoS to Queue and Queue to CoS Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list
• Class of Service
Select CoS value from this drop-down list
