4.7.5 MLD Snooping Statics
This page provides MLD Snooping Statics. The MLD Snooping Statics screen in Figure 4-7-34 appears.
Figure 4-7-34 Forward All Setting Page Screenshot
The page includes the following fields:
Object Description
• Total RX
Display current total RX
• Valid RX
Display current valid RX
• Invalid RX
Display current invalid RX
• Other RX
Display current other RX
• Leave RX
Display current leave RX
• Report RX
Display current report RX
• General Query RX
Display current general query RX
• Special Group Query
RX
Display current special group query RX
• Special Group &
Source Query RX
Display current special group & source query RX
