User’s Manual of WGS Managed Series
4.10.3 IPv4-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific
ACE is not applied to the hardware due to hardware limitations. IPv4-based ACL screens in Figure 4-10-5 & Figure 4-10-6
appear.
Figure 4-10-5 IPv4-based ACL Page Screenshot
The page includes the following fields:
Object Description
• ACL Name
Create a named IPv4-based ACL list
Buttons
: Click to add ACL name list.
Figure 4-10-6 ACL Table Page Screenshot
The page includes the following fields:
Object Description
• Delete
Click to delete ACL name entry.
