User’s Manual of WGS Managed Series
Buttons
: Click to apply changes.
Figure 4-9-44 Option82 Global Setting Page Screenshot
The page includes the following fields:
Object Description
• Option82 Remote ID
Display the current option82 remote ID
4.9.7.9 Option82 Port Setting
This function is used to set the retransmitting policy of the system for the received DHCP request message which contains
option82.
The drop mode means that if the message has option82, then the system will drop it without processing.
The keep mode means that the system will keep the original option82 segment in the message, and forward it to the
server to process
The replace mode means that the system will replace the option 82 segment in the existing message with its own
option 82, and forward the message to the server to process.
Option82 Port Setting screens in Figure 4-9-45 & Figure 4-9-46 appear.
Figure 4-9-45 Option82 Global Setting Page Screenshot
