User’s Manual of WGS Managed Series
• Optional TLVs
If the LLDP MED extended power via MDI packets were sent, or if they were
overloaded
• MED Inventory
Displays if the mandatory group of TLVs was transmitted or overloaded
• 802.1 TLVs
Displays if the 802.1 TLVs were transmitted or overloaded
4.12.9 LLDP Statistics
Use the LLDP Device Statistics screen to general statistics for LLDP-capable devices attached to the switch, and for LLDP
protocol messages transmitted or received on all local interfaces. The LLDP Global and Port Statistics screens in Figure
4-12-17 & Figure 4-12-18 appear.
Figure 4-12-17 LLDP Global Statistics Page Screenshot
The page includes the following fields:
Object Description
• Insertions
Shows the number of new entries added since switch reboot.\
• Deletions
Shows the number of new entries deleted since switch reboot.\
• Drops
Shows the number of LLDP frames dropped due to that the entry table was full.\
• Age Outs
Shows the number of entries deleted due to Time-To-Live expiring.\
Buttons
: Click to clear the statistics
: Click to refresh the statistics
