4.11.3 Dynamic Address Setting
By default, dynamic entries are removed from the MAC table after 300 seconds. The Dynamic Address Setting/Status screens
in Figure 4-11-5 & Figure 4-11-6 appear.
Figure 4-11-5 Dynamic Addresses Setting Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
The time after which a learned entry is discarded
Range: 10-630 seconds;
Default: 300 seconds
Buttons
: Click to apply changes.
Figure 4-11-6 Dynamic Addresses Status Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
Display the current aging time
