User’s Manual of WGS Managed Series
• Duplex
Display the current duplex mode
• Flow Control Config
Display the current flow control configuration
• Flow Control Status
Display the current flow control status
4.4.4 LACP Setting
This page is used to configure the LACP system priority setting. The LACP Setting screens in Figure 4-4-8 & Figure 4-4-9
appear.
Figure 4-4-8 LACP Setting Page Screenshot
The page includes the following fields:
Object Description
• System Priority
A value which is used to identify the active LACP.
The Managed Switch with the lowest value has the highest priority and is
selected as the active LACP peer of the trunk group.
Buttons
: Click to apply changes.
Figure 4-4-9 LACP Information Page Screenshot
The page includes the following fields:
Object Description
• System Priority
Display the current system priority.
