User’s Manual of WGS Managed Series
205
4.8.2.2 QoS Port Settings
The QoS Port Settings and Status screen in Figure 4-8-3 & Figure 4-8-4 appear.
Figure 4-8-3 QoS Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number from this drop-down list
• CoS Value
Select CoS value from this drop-down list
• Remark CoS
Disable or enable remark CoS
• Remark DSCP
Disable or enable remark DSCP
• Remark IP Precedence
Disable or enable remark IP Precedence
Buttons
: Click to apply changes.
 QoS Port Status
Figure 4-8-4 QoS Port Status Page Screenshot
