User’s Manual of WGS Managed Series
4.12.5 LLDP Remove Device
This page provides a status overview for all LLDP remove devices. The displayed table contains a row for each port on which an
LLDP neighbor is detected. The LLDP Remove Device screen in Figure 4-12-9 appears.
Figure 4-12-9 LLDP Remote Device Page Screenshot
The page includes the following fields:
Object Description
• Local Port
Display the current local port
• Chassis ID Subtype
Display the current chassis ID subtype
• Chassis ID
The Chassis ID is the identification of the neighbor's LLDP frames
• Port ID Subtype
Display the current port ID subtype
• Port ID
The Remote Port ID is the identification of the neighbor port
• System Name
System Name is the name advertised by the neighbor unit
• Time to Live
Display the current time to live
Buttons
: Click to delete LLDP remove device entry.
: Click to refresh LLDP remove device.
