User’s Manual of WGS Managed Series
121
The page includes the following fields:
Object Description
• Port Name
The switch port number of the logical port
• Priority
Display the current LACP priority parameter
• Timeout
Display the current timeout parameter
4.4.6 LAG Status
This page displays LAG status. The LAG Status screens in Figure 4-4-12 & Figure 4-4-13 appear.
Figure 4-4-12 LAG Status Page Screenshot
The page includes the following fields:
Object Description
• LAG
Display the current trunk entry
• Name
Display the current LAG name
• Type
Display the current trunk type
• Link State
Display the current link state
• Active Member
Display the current active member
• Standby Member
Display the current standby member
Figure 4-4-13 LACP Information Page Screenshot
