User’s Manual of WGS Managed Series
122
The page includes the following fields:
Object Description
• Trunk
Display the current trunk ID
• Port
Display the current port number
• PartnerSysId
The system ID of link partner. This field would be updated when the port receives
LACP PDU from link partner
• PnKey
Port key of partner. This field would be updated when the port receives LACP
PDU from link partner
• AtKey
Port key of actor. The key is designed to be the same as trunk ID.
• Sel
LACP selection logic status of the port
 “S” means selected
 “U” means unselected
 “D” means standby
• Mux
LACP mux state machine status of the port
 “DETACH” means the port is in detached state
 “WAIT” means waiting state
 “ATTACH” means attach state
 “CLLCT” means collecting state
 “DSTRBT” means distributing state
• Receiv
LACP receive state machine status of the port
 “INIT” means the port is in initialize state
 “PORTds” means port disabled state
 “EXPR” means expired state
 “LACPds” means LACP disabled state
 “DFLT” means defaulted state
 “CRRNT” means current state
• PrdTx
LACP periodic transmission state machine status of the port
 “no PRD” means the port is in no periodic state
 “FstPRD” means fast periodic state
 “SlwPRD” means slow periodic state
 “PrdTX” means periodic TX state
• AtState
The actor state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
“Expired”.
The contents could be true or false. If the contents are false, the web shows “_”; if
the contents are true, the web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and “E” for
each content respectively.
• PnState
The partner state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
