Planet WGS-4215-T User Manual

User’s Manual of WGS Managed Series
299
4.10.7 ACL Binding
This page allows you to bind the Policy content to the appropriate ACLs. The ACL Policy screens in Figure 4-10-13 & Figure
4-10-14 appears.
Figure 4-10-13 ACL Binding Page Screenshot
The page includes the following fields:
Object Description
• Binding Port
Select port from this drop-down list
• ACL Select
Select ACL list from this drop-down list
Buttons
: Click to apply changes.
Figure 4-10-14 ACL Binding Table Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port
• MAC ACL
Display the current MAC ACL
• IPv4 ACL
Display the current IPv4 ACL
• IPv6 ACL
Display the current IPv6 ACL
• Modify
Click to edit ACL binding table parameter
Click to delete ACL binding entry
