User’s Manual of WGS Managed Series
4.2.7.7 SNMPv1, 2 Notification Recipients
Configure SNMPv1 and 2 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-31 &
Figure 4-2-32 appear.
Figure 4-2-31 SNMPv1, 2 Notification Recipients Page Screenshot
The page includes the following fields:
Object Description
• Server Address
Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
• SNMP Version
Indicates the SNMP trap supported version. Possible versions are:
SNMP v1: Set SNMP trap supported version 1.
SNMP v2c: Set SNMP trap supported version 2c.
• Notify Type
Set the notify type in traps or informs.
• Community Name
Indicates the community access string when send SNMP trap packet.
• UDP Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
• Time Out
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
• Retries
Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
Buttons
: Click to add a new SNMPv1, 2 host entry.
Figure 4-2-32 SNMPv1, 2 Host Status Page Screenshot
