User’s Manual of WGS Managed Series
4.9.8.5 Rate Limit
The ARP Rate Limit Setting and Config screens in Figure 4-9-56 & Figure 4-9-57 appear.
Figure 4-9-56 ARP Rate Limit Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• State
Set default or user-define
• Rate Limit (pps)
Configure the rate limit for the port policer. The default value is "unlimited".
Buttons
: Click to apply changes.
Figure 4-9-57 ARP Rate Limit Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port
• Rate Limit (pps)
Display the current rate limit
