User’s Manual of WGS Managed Series
186
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list to assign IGMP membership
• Port
The switch port number of the logical port
• Membership
Select IGMP membership for each interface:
Forbidden: Interface is forbidden from automatically joining the IGMP via MVR.
None: Interface is not a member of the VLAN. Packets associated with this
VLAN will not be transmitted by the interface.
Static: Interface is a member of the IGMP.
Buttons
: Click to apply changes.
4.7.3 IGMP Snooping Statics
This page provides IGMP Snooping Statics. The IGMP Snooping Statics screen in Figure 4-7-21 appears.
Figure 4-7-21 Forward All Setting Page Screenshot
