User’s Manual of WGS Managed Series
4.10.1 MAC-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific
ACE is not applied to the hardware due to hardware limitations. MAC-based ACL screens in Figure 4-10-1 & Figure 4-10-2
appear.
Figure 4-10-1 MAC-based ACL Page Screenshot
The page includes the following fields:
Object Description
• ACL Name
Create a named MAC-based ACL list
ACL Table
Figure 4-10-2 ACL Table Page Screenshot
The page includes the following fields:
Object Description
• Delete
Click to delete ACL name entry
