User’s Manual of WGS Managed Series
4.8.3.2 Port Settings
The QoS Port Setting and Status screen in Figure 4-8-15 & Figure 4-8-16 appear.
Figure 4-8-15 Basic Mode Global Settings Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port number from this drop-down list
• Trust Mode
Enable or disable the trust mode
Buttons
: Click to apply changes.
Figure 4-8-16 QoS Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port
• Trust Mode
Display the current trust type
