User’s Manual of WGS Managed Series
184
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Static Ports
Display the current static ports
• Forbidden Ports
Display the current forbidden ports
• Modify
Click to edit parameter
Click to delete the group ID entry
4.7.2.6 IGMP Router Table
This page provides Router Table. The Dynamic, Static and Forbidden Router Table screens in Figure 4-7-17, Figure 4-7-18 &
Figure 4-7-19 appear.
Figure 4-7-17 Dynamic Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Port
Display the current dynamic router ports
• Expiry Time (Sec)
Display the current expiry time
Figure 4-7-18 Static Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Port Mask
Display the current port mask
