User’s Manual of WGS Managed Series
Buttons
: Click to apply changes.
Figure 4-7-40 Port Filter Status Page Screenshot
The page includes the following fields:
Object Description
• Port
Display the current port
• Filter Profile ID
Display the current filter profile ID
• Action
Click to display detail profile parameter
Click to delete the IGMP filter profile entry
4.7.7.3 MLD Filter Setting
The Filter Setting and Status screens in Figure 4-7-41 & Figure 4-7-42 appear.
Figure 4-7-41 Filter Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number from this drop-down list
• Filter Profile ID
Select filter profile ID from this drop-down list
