User’s Manual of WGS Managed Series
21
Power Consumption/
Dissipation
Max. 152 watts/519 BTU Max. 210 watts/716 BTU Max. 253 watts/868 BTU
Dimensions (W x D x H) 148 x 25 x 134 mm 178 x 25 x 134 mm 245 x 24.4 x 140 mm
Weight
532g 640g 1090g
ESD Protection Contact Discharge 6KV DC
Air Discharge 8KV DC
Enclosure Metal
Installation Wall mount, magnetic wall mount and DIN-rail kit
Power over Ethernet
PoE Standard IEEE 802.3af / 802.3at Power over Ethernet PSE
PoE Power Supply Type End-span
PoE Power Output
IEEE 802.3af Standard
- Per port 48V~56V DC (depending on the power supply), max. 15.4 watts
IEEE 802.3at Standard
- Per port 50V~56V DC (depending on the power supply), max. 36 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget 144 watts (depending on
power input)
200 watts (depending on
power input)
240 watts (depending on
power input)
Max. Number of Class 2 PDs 4 8 16
Max. Number of Class 3 PDs 4 8 16
Max. Number of Class 4 PDs
4 7 9
Layer 2 Functions
Port Mirroring
TX/RX/Both
Many-to-1 monitor
VLAN
802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Management VLAN
Link Aggregation
IEEE 802.3ad LACP and static trunk
Supports 4 groups with 4 ports per trunk (WGS-804HPT)
Supports 1 groups with 2 SFP ports per trunk(WGS-4215 PoE Series)
Spanning Tree Protocol
STP, IEEE 802.1D Spanning Tree Protocol
RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
MSTP, IEEE 802.1s Multiple Spanning Tree Protocol
STP BPDU Guard, BPDU Filtering and BPDU Forwarding
IGMP Snooping
IPv4 IGMP (v2/v3) snooping
IGMP querier
Up to 256 multicast groups
MLD Snooping IPv6 MLD (v1/v2) snooping, up to 256 multicast groups
