User’s Manual of WGS Managed Series
Valid values for frame type ranges from 0x0600-0xfffe
Buttons
: Click to apply changes.
Figure 4-5-10 Protocol VLAN Group State Page Screenshot
The page includes the following fields:
Object Description
• Group ID
Display the current group ID
• Frame Type
Display the current frame type
• Protocol Value
Display the current protocol value
• Delete
Click to delete the group ID entry
