User’s Manual of WGS Managed Series
160
RSTP-Operation and MSTP-Operation.
• Configuration Name
Identifier used to identify the configuration currently being used.
• Configuration Revision
Identifier used to identify the configuration currently being used.
The values allowed are between 0 and 65535.
The default value is 0.
Buttons
: Click to apply changes.
Figure 4-6-5 STP Information Page Screenshot
The page includes the following fields:
Object Description
• STP
Display the current STP state
• BPDU Forward
Display the current BPDU forward mode
• Cost Method
Display the current cost method
• Force Version
Display the current force version
• Configuration Name
Display the current configuration name
• Configuration Revision
Display the current configuration revision
