User’s Manual of WGS Managed Series
Figure 4-6-7 STP Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• Admin Enable
Display the current STP port mode status
• External Cost
Display the current external cost.
• Edge Port
Display the current edge port status.
• BPDU Filter
Display the current BPDU filter configuration.
• BPDU Guard
Display the current BPDU guard configuration.
• P2P MAC
Display the current P2P MAC status.
