Planet WGS-4215-T User Manual

User’s Manual of WGS Managed Series
169
• VLAN List
Display the current VLAN list
• VLAN Count
Display the current VLAN count
• Priority
Display the current MSTI priority
Figure 4-6-14 MST Instance Status Page Screenshot
The page includes the following fields:
Object Description
• MSTI ID
Display the MSTI ID.
• Regional Root Bridge
Display the current designated root bridge
• Internal Root Cost
Display the current internal root cost
• Designated Bridge
Display the current designated bridge
• Root Port
Display the current root port.
• Max Age
Display the current max. age.
• Forward Delay
Display the current forward delay.
• Remaining Hops
Display the current remaining hops.
• Last Topology Change
Display the current last topology change.
