User’s Manual of WGS Managed Series
252
The DHCP Snooping VLAN Setting screens in Figure 4-9-34 & Figure 4-9-35 appear.
Figure 4-9-34 DHCP Snooping VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN List
Indicates the ID of this particular VLAN.
• Status
Indicates the DHCP snooping mode operation. Possible modes are:
 Enabled: Enable DHCP snooping mode operation.
When enable DHCP snooping mode operation, the request
DHCP messages will be forwarded to trusted ports and only
allowed reply packets from trusted ports.
 Disabled: Disable DHCP snooping mode operation.
Buttons
: Click to apply changes.
Figure 4-9-35 DHCP Snooping VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN List
Display the current VLAN list
• Status
Display the current DHCP snooping status
