User’s Manual of WGS Managed Series

254

Buttons

: Click to apply changes.

Figure 4-9-37 DHCP Snooping Port Setting Page Screenshot

The page includes the following fields:

Object Description

• Port

The switch port number of the logical port

• Type

Display the current type

• Chaddr Check

Display the current chaddr check
