User’s Manual of WGS Managed Series
and reconnected on the port (by disconnecting the cable), the port will
remain shut down. There are three ways to re-open the port:
1) Disable and re-enable Limit Control on the port or the switch,
2) Click the Reopen button.
Discard: If Limit + 1 MAC addresses is seen on the port, it will trigger the
action that do not learn the new MAC and drop the package.
Buttons
: Click to apply changes.
Figure 4-9-63 Port Security Status Page Screenshot
The page includes the following fields:
Object Description
• Port Name
The switch port number of the logical port
• Enable State
Display the current per port security status
• L2 Entry Num
Display the current L2 entry number
• Action
Display the current action
