User’s Manual of WGS Managed Series
The Copper test and test result screens in Figure 4-13-1 & Figure 4-13-2 appear.
Figure 4-13-1 Copper Test Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
Buttons
: Click to run the diagnostics
Figure 4-13-2 Test Results Page Screenshot
The page includes the following fields:
Object Description
• Port
The port where you are requesting Cable Diagnostics
• Channel A~D
Display the current channel status
• Cable Length A~D
Display the current cable length
• Result
Display the test result
