User’s Manual of WGS Managed Series
33
■ 10/100/1000BASE-T Interfaces (Port-5 to Port-8)
LED Color Function
LNK/ACT Green
Lights: To indicate the link through that port is successfully established.
Blinks: To indicate that the switch is actively sending or receiving data over that port.
1000 Green
Lights: To indicate that the port is operating at 1000Mbps.
Off: If LNK/ACT LED is Off, it indicates that the port is link-down or operating at
10/100Mbps
■ PoE Power Usage (Unit: Watt)
LED Color Function
30
Green Lights:
To indicate the system consumes over 30-watt PoE power budget
60
Green Lights:
To indicate the system consumes over 60-watt PoE power budget
90
Green Lights:
To indicate the system consumes over 90-watt PoE power budget
120
Green Lights:
To indicate the system consumes over 120-watt PoE power budget
