User’s Manual of WGS Managed Series
343
This section displays the PoE Power Usage of Current Power Consumption as Figure 4-15-3 shows.
Figure 4-15-3 Current Power Consumption Screenshot
This section allows the user to inspect and configure the current PoE port settings
as Figure 4-15-4 shows.
Figure 4-15-4 Power over Ethernet Configuration Screenshot
The page includes the following fields:
Object Description
• PoE Mode
There are three modes for PoE mode.
 Enable: enable PoE function..
 Disable: disable PoE function.
 Schedule: enable PoE function in schedule mode.
• Schedule
Indicates the scheduled profile mode. Possible profiles are:
 Profile1
 Profile2
 Profile3
 Profile4
• Priority
The Priority represents PoE ports priority. There are three levels of power priority
named Low, High and Critical.
