Planmeca ProMax Technical Manual

Chapter A - GENERAL & TECHNICAL DATA
A-8 Planmeca ProMax
USER’S STATEMENT
Technical Manual
Single load rating of X-ray tube
Target material of the X-ray tube
Tungsten anode
Reference axis to which the target angle and the focal spot
characteristics of the X-ray tube refer
90° with respect to the anode-cathode axis (pan/ceph)
86.5° with respect to the anode-cathode axis (3D/3D s/pan/ceph)
Target angle with respect to the reference axis
5°
Filtration in terms of quality equivalent filtration of the X-ray tube
Inherent filtration at least 0.8 Al/50 kV according to IEC 522/1976
EXPOSURE TIME (s)
TUBE CURRENT (mA)

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
