Planmeca ProMax Technical Manual

Chapter C - HELP & ERROR MESSAGES
Planmeca ProMax C-15
ERROR MESSAGES
Technical Manual
3.7 System conflicts (8xx)
Error
code
Explanation Comments
E801 Missing MCM
module
1 - shoulder motor MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E802 2 - elbow motor MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E803 3 - temple support/digital CEPH scan MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E804 4 - C-arm rotation motor MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E805 5 - receptor pan / X&Y collimation MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E806 6 - receptor rotation MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E807 7 - receptor lift / X&Y collimation
(reserved option)
MCM PCB is broken or badly
connected to the PSU PCB.
Check also the functionality of
the PSU and CPU PCB.
E808 8 - tube head lift function (reserved
option)
