Planmeca ProMax Technical Manual

Chapter E - C-ARM AND IMAGING ARM
E-96 Planmeca ProMax
REPLACING PCBs
Technical Manual
8 REPLACING PCBs
8.1 C-arm PCB
a) Remove the C-arm upper and inner covers, the cassette carriage/sensor head covers and
tube head inner cover as described in section 5 “REMOVING THE COVERS” on page E-77.
b) Disconnect all the cables that are connected to the C-arm PCB.
c) Unscrew the C-arm PCB attachment screws with 2.5mm Allen key and remove the PCB (Fig.
131, 1).
d) Install the new C-arm PCB in reverse order. Connect the cables as shown in Fig. 131.
Figure 131
1
Digi_C-ArmPCB.eps
M4x6 DIN 7984
1
3
2
J24J23J22J21
121-10-05
C-Arm PCB
J26
J19
J27
J10
J9
J7
J1 J2
J5
J3
J4
J6
J8
J11
J25
J20
J18
C-Arm
Angle Sensor
T
o
p
L
e
ft
L
a
s
e
r
T
o
p
C
e
n
te
r
L
a
s
e
r
T
o
p
R
ig
h
t
L
a
s
e
r
J1
121-10-08
J1
121-10-08
J1
121-10-08
Receptor Pan Motor
C-Arm Motor
Receptor Rotation Motor
X-Collimator Motor
Y-Collimator Motor
CAM
J1
J2
J3
J5
DIMAX2
PA N
CH4
Receptor Pan / Primary Collimator
C-Arm Rotation Motor
Primary Collimator / Aux. (J20)
Receptor Rocation
Aux. (J18)
CH5 CH6
CH7 CH8
Aux.
Aux.
