Planmeca ProMax Technical Manual

Chapter C - HELP & ERROR MESSAGES
C-4 Planmeca ProMax
ERROR MESSAGES
Technical Manual
3 ERROR MESSAGES
3.1 Motorized motion related errors (2xx)
Error
code
Explanation Comments
E201 MCM (motor control
module) module
overheated
1 - shoulder motor Exposure interrupted.
E202 2 - elbow motor Exposure interrupted.
E203 3 - temple support/Dimax3 CEPH scan Exposure interrupted.
E204 4 - C-arm rotation motor Exposure interrupted.
E205 5 - receptor pan / X&Y collimation Exposure interrupted.
E206 6 - receptor rotation Exposure interrupted.
E207 7 - for receptor lift (reserved option)/ X&Y
collimation
Exposure interrupted.
E208 8 - for tube head lift function (reserved
option)
Exposure interrupted.
E210 Open circuit in 0 - lift motor
E211 1 - shoulder motor PCB Check the motor, interface and
cable.
E212 2 - elbow motor Check the motor, interface and
cable.
E213 3 - temple rest motor Check the motor, interface and
cable.
E214 4 - Dimax3 CEPH scan motor (or CEPH
marking motor depending on version)
Check the motor, interface and
cable.
E215 5 - C-arm rotation motor Check the motor, interface and
cable.
E216 6 - receptor pan motor Check the motor, interface and
cable.
E217 7 - X-collimator motor Check the motor, interface and
cable.
E218 8 - Y-collimator motor Check the motor, interface and
cable.
E219 9 - receptor rotation motor Check the motor, interface and
cable.
E220 10 - receptor lift motor (reserved option)
E221 11 - tube head lift motor (reserved option)

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
