Planmeca ProMax Technical Manual

Chapter G - COLUMN
G-10 Planmeca ProMax
REMOVING THE COVERS
Technical Manual
2.2 Removing the telescopic column rear cover plates
Remove the two rear cover plates of the telescopic column as follows. Switch the unit on and
drive the telescopic column to the uppermost position (Fig. 30, 1). Switch the unit off. Detach
the upper inner corner of the cover plate by carefully pulling it outwards (Fig. 30, 2). Detach
the cover plate by pushing the cover plate inwards (see small arrows in the figure below) (Fig.
30, 3).
Figure 30
2
1
3
3
Rem_column_backc.eps

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
