Chapter A - GENERAL & TECHNICAL DATA
Planmeca ProMax A-3
TECHNICAL SPECIFICATIONS
Technical Manual
4 TECHNICAL SPECIFICATIONS
Generator Resonant-mode, DSP-controlled, 80...160 kHz
complies with the standard IEC 60601-2-7: 1998
X-ray tube Toshiba D-054SB-P
Focal spot size 0.5 x 0.5mm
according to IEC 60336
Total filtration:
Panoramic min. 2.5 mm Al
Cephalometric min. 2.5 mm Al
Tomographic min. 2.5 mm Al
3D / 3D s min. 2.5 mm Al + 0.5 Cu
Anode voltage Tomo 54 - 84 kV ±5%
Panoramic 54 - 84 kV ±5%
Cephalometric 60 - 84 kV ±5%
3D/3Ds 50-90kV±5%
Anode current Tomo 1 - 16 mA ±10%
Panoramic 1 - 16 mA ±10%
Cephalometric 1 - 16 mA ±10%
3D / 3D s 1 - 16 mA ±10%
Linearity of radiation output < 0.1
Cooling period Automatically controlled
Exposure time Panoramic 2.5 - 16 s as indicated ±10%
Tomo 4 - 12 s as indicated ±10%
Transtomo 24 - 95 s as indicated ±10%
Ceph / Normal 12 - 18.7 s as indicated ±10%
Ceph / High speed 6 - 9.3 s as indicated ±10%
3D / 3D s Pulsed, effective 2.4 - 12 s
SID Panoramic and Tomo 500 mm (19.68 in.)
Cephalometric 170 cm (66.92 in.)
3D / 3D s 527 mm (20.74 in.)
Magnification Panoramic constant 1.2
Tomo constant 1.5
Cephalometric constant 1.13
3D / 3D s constant 1.57
Pan / ceph image properties:
CCD pixel size 33 m
Image pixel size 99/130 m
CCD active surface Panoramic 9 x 136 mm (0.35 x 5.35 in.)
Cephalometric 9 x 270 mm (0.35 x 10.6 in.)
Image field Panoramic 14 x 30 cm (5.5 x 12 in.)
Cephalometric 27 x 30 cm (11 x 12 in.)
3D image properties:
Flat panel pixel size 127 m
Flat panel active surface 3D: 13 x 13 cm (5.1 x 5.1 in.)
3D s: 8 x 13 cm (3.2 x 5.1 in.)
