Planmeca ProMax Technical Manual

Chapter C - HELP & ERROR MESSAGES
C-14 Planmeca ProMax
ERROR MESSAGES
Technical Manual
3.6 Calibration errors (7xx)
Error
code
Explanation Comments
E701 Missing calibration Tube head filament definition not done Perform the preheat calibration
again.
E702 Tube head kV-calibration not done Perform the preheat calibration
again.
E703 Panoramic DEC not calibrated Calibrate the DEC-PAN.
E704 Cephalometric DEC not calibrated Calibrate the DEC-CEPH.
E705 Preheat calibration Problem during the preheat calibration. The current in the tube head is
not high enough. Perform the
preheat calibration again.
E706 Problem with the preheat calibration. The current in the tube head is
not raising on the voltage area.
Perform the preheat calibration
again. Check the functionality of
the tube head.
E710 Primary collimator Primary y-collimator opening is too big. Adjust the lower blade upwards
or the upper blade downwards.
E711 3D primary x-collimator opening is too
wide.
Adjust the left blade to right or the
right blade to left.

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
