Planmeca ProMax Technical Manual

Planmeca ProMax B-1
Chapter
Technical Manual
B INFORMATION DISPLAYS
1 GENERAL ABOUT INFORMATION DISPLAYS
CAUTION Some of the information displays can be used to alter the operation of the unit. Never
use functions that you are not familiar with.
The unit has a number of additional functions for special requirements. The function modes
that can be entered without a password are: User preference settings, Feature program
control and Special functions. Service settings, Technical calibrations and
Troubleshooting are for the use of service personnel only and are protected with a
password. The additional functions are entered as follows: Touch the i field on the Main
display. The list of Information displays appears.
Figure 1
You can return to the Main display by touching the Exit field. You can return to the previous
display by touching the Back field in the lower right corner.

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
