Planmeca ProMax Technical Manual

Chapter C - HELP & ERROR MESSAGES
Planmeca ProMax C-3
HELP MESSAGES
Technical Manual
H171 User related
messages
Dimax sensor not attached properly to C-
arm
Sensor has not been attached
and/or locked in position.
H172 Dimax sensor not attached properly to
Cephalostat
Sensor has not been attached
and/or locked in position.
H175 PC program selection in conflict with
selected ProMax X-ray unit program
Wrong exposure mode has been
selected on the PC.
H176 Safety area limit violation. Change the values for layer thick-
ness, position or angle.
H177 One or more image layers will not be
exposed with these settings
Change the exposure settings.
H178 Imaging impossible with selected set-
tings.
Change the exposure settings.
H180 DEC not available
H181 Exposure interrupted by the workstation
H182 Timeout in image data transmission
H183 Attached sensor is not suitable for the
selected program.
H184 Move 3D sensor aside.
H185 3D sensor not attached properly.
H186 No IP address defined for 3D sensor.
H187 Exposure interrupted by reconstruction
PC due to data transmission fault.
H192 It is not possible to enable radiation or
PC communication (i410) when demo
licenses are switched on (i510).
First switch off demo licenses
(i510), then enable radiation or
PC communication (i410).
Error
code
Explanation Comments

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
