Planmeca ProMax Technical Manual

Chapter A - GENERAL & TECHNICAL DATA
A-18 Planmeca ProMax
PROMAX 3D: STRAY RADIATION MEASUREMENTS
Technical Manual
Figure 6 Stray radiation measurements with exposure values 84 kV and 16 mA,
normal resolution
Figure 7 Stray radiation measurements with exposure values 84 kV and 8 mA, low dose
3000mm
500mm
500mm
3000mm
10 1 6 15 11 7
19 26 2 40 17 10
26 60 34 12
24 63 37 13
18 35 64 37 20 10
13 20 26 18 10 7
Normal_resolution_84kV_16mA_3DS.eps
3000mm
500mm
500mm
3000mm
92518127
18 20 2 48 17 9
28 65 23 9
24 64 35 12
18 36 67 31 21 11
13 21 28 19 10 7
Low_dose_84kV_8mA_3DS.eps

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
