Polaris RZR 800 2013 User Manual

1.8
9924882 - 2013–2014 RZR 800
© Copyright Polaris Sales Inc.
Engine
DC Outlet Standard 12 Volt
Relays
Chassis / EFI / Fan
Fuel Pump / EPS
Circuit Breaker
Fan Motor: 20 Amp
Fuses (Fuse/Relay Box)
Drive / Fuel Pump: 10 Amp
Lights / EFI / Accessory: 20 Amp
Fuses (Power Fuse Holder)
EFI: 20 Amp
Chassis / EPS: 30 Amp
Drivetrain
Transmission Type
Polaris Automatic PVT
Drive Ratio - Front 3.82:1
Drive Ratio - Final 3.70:1
Shift Type
In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity
Polaris Demand Drive
6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity
Polaris AGL
24 oz. (710 ml)
Transmission: Transfer Case
Fluid Type / Capacity
Polaris AGL
14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity
Polaris Premium ADF
26 oz. (769 ml)
Clutch Type (Standard Model)
Standard PVT
Clutch Type (EPS Model)
PVT with EBS
Drive Belt 3211113
Steering / Suspension
Front Suspension
Independent Dual A-arm
w/Anti-Sway Bar
Front Travel 9 in. / 23 cm
Rear Suspension Rolled IRS w/Anti-Sway Bar
Rear Travel 9.5 in. / 24 cm
Shock Preload Adjustment
Front / Rear
Cam Adjustment
Toe Out
1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Type / Size
Steel / 12 x 6
Aluminum / 12 x 6
Rear Wheel Type / Size
Steel / 12 x 8
Aluminum / 12 x 8
Front Tire Type / Size
Ancla / 25 x 8 R12
Maxxis / 25 x 8 R12
Rear Tire Type / Size
Ancla / 25 x 10 R12
Maxxis / 25 x 10 R12
Tire Air Pressure - Front / Rear
8 psi (55 kPa)
Brake - Front / Rear
Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
CLUTCH CHART (All Non-EPS Models)
Altitude
Shift
Weight
Drive
Spring
Driven
Spring
Meters
(Feet)
0-1500
(0-5000)
23-62
(5632337)
Green
(7043789)
Blk / Almond
(7043167)
1500-3700
(5000 - 12000)
23-58 (B)
(1322911)
Green
(7043789)
Blk / Almond
(7043167)
CLUTCH CHART (EPS Model with EBS)
Altitude
Shift
Weight
Drive
Spring
Driven
Spring
Meters
(Feet)
0-1500
(0-5000)
23-66
(5632763)
Green
(7043789)
Red
(3234452)
1500-3700
(5000 - 12000)
23-62
(5632337)
Green
(7043789)
Red
(3234452)
