7.66
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
Gearcase Exploded View
Ref#
Description Qty
Ref#
Description Qty
1 Screw 2 20 Screw 8
2 Screw 2 21
Lever, Shift
1
3
Bracket, Rear Mount, RH
1 22
Spring, Shift Lever
1
4
Bracket, Rear Mount, LH
1 23
Spring, Shift Return
2
5
Mount, Rear
1 24 Pin Lock Asm. 1
6
Nut, Flanged
2 25 Seal 1
7
Assembly, Rear Housing, RH
1 26
Bushing, Dowel
2
8
Plug, Fill w/O-Ring
1 27
Solenoid, Diff Lock
1
9
Bushing, Pin Lock
1 28
Bearing, Tapered Roller
1
10
Bearing, Ball
2 29
Screw, Flange Head
10
11
Plug, Drain
1 30
Case, Diff Cover Half
1
12 Shim Kit 2 31
Thrust Washer, Pinion
2
13
Gear, Clutch
1 32
Gear, Diff, Pinion Mate
2
14
Yoke, Shift
1 33
Gear, Diff Side
2
15 N/A 1 34
Thrust Washer, Side Gear
1
16
Cover Asm., Rear
1 35
Case, Diff Half
1
17 Screw 2 36
Pin, Diff, Cross
1
18
Seal, Oil
2 37
Pin, Spring
1
19
Screw, Flanged
4
FINAL DRIVE
