Bearing Carrier Installation
1. Install drive shaft axle through the backside of the
bearing carrier.
2. Install the upper and lower ball joint ends into the
front bearing carrier.
3. Install pinch bolts and torque to specification.
Ball Joint Pinch Bolts:
23 ft-lbs (31 Nm)
4. Apply grease to drive shaft axle splines.
