Shock Compression Adjustment
The compression damping adjustment is located on top
of the shock ‘Piggyback’ reservoir of each shock.
Turn the clicker adjuster knob to make damping
adjustments.
NOTE: When the clicker adjuster is turned
clockwise until it stops, the damping is in the fully
closed position.
Turn the clicker clockwise to increase compression
damping. Turn the clicker counter-clockwise to decrease
compression damping.
NOTE: The factory setting is 10 clicks from closed.
Refer to the “Compression Adjustment Table” below.
Compression Adjustment Table
Setting Compression Damping
Softest
Full counter-clockwise position
Factory
10 clicks from closed
Firmest 2 clicks from closed
BRAKE SYSTEM
Brake Fluid Inspection
Always check the brake pedal travel and inspect the
brake fluid reservoir level before each operation. If the
fluid level is low, add DOT 4 brake fluid only.
Recommended Brake Fluid:
DOT 4 Brake Fluid
(PN 2872189)
Brake fluid should be changed every two years. The fluid
should also be changed anytime the fluid becomes
contaminated, the fluid level is below the minimum level,
or if the type and brand of the fluid in the reservoir is
unknown.
The brake fluid master cylinder reservoir can be
accessed through the left front wheel well.
1. Position the vehicle on a level surface.
2. Place the transmission in PARK (P).
3. View the brake fluid level in the reservoir. The level
should be between the MAX and MIN level lines.
4. If the fluid level is lower than the MIN level line, add
brake fluid until it reaches the MAX level line.
5. Install the reservoir cap and apply the brake pedal
forcefully for a few seconds and check for fluid
leakage around the master cylinder fittings and the
brake caliper fittings.
