3
3.53
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
41. Remove and inspect crankshaft main journal
bearings for abnormal wear. It is recommended to
replace the bearings anytime the engine is
disassembled.
Camshaft Inspection
1. Thoroughly clean the cam shaft.
2. Visually inspect each cam lobe for wear, chafing or
damage.
3. Measure height of each cam lobe using a
micrometer. Compare to specification.
Cam Lobe Height
Intake (Std):
1.357” (34.477 mm)
Exhaust (Std.):
1.342” (34.096 mm)
ENGINE
