Polaris RZR 800 2013 User Manual

1.16
9924882 - 2013–2014 RZR 800
© Copyright Polaris Sales Inc.
Standard Bolt Torque Specification
Bolt Size
Grade 2
Ft. Lbs. (Nm)
Grade 5
Ft. Lbs. (Nm)
Grade 8
Ft. Lbs. (Nm)
1/4-20
5 (7) 8 (11) 12 (16)
1/4-28
6 (8) 10 (14) 14 (19)
5/16-18
11 (15) 17 (23) 25 (35)
5/16-24
12 (16) 19 (26) 29 (40)
3/8-16
20 (27) 30 (40) 45 (62)
3/8-24
23 (32) 35 (48) 50 (69)
7/16-14
30 (40) 50 (69) 70 (97)
7/16-20
35 (48) 55 (76) 80 (110)
1/2-13
50 (69) 75 (104) 110 (152)
1/2-20
55 (76) 90 (124) 120 (166)
Metric Bolt Torque Specification
Bolt Size
Grade
4.6 4.8 8.8 / 8.9 10.9 12.9
Ft.— Lbs. (Nm) Dry Threads
M3
.3 (.5) .5 (.7) 1 (1.3) 1.5 (2) 1.5 (2)
M4
.8 (1.1) 1 (1.5) 2 (3) 3 (4.5) 4 (5)
M5
1.5 (2.5) 2 (3) 4.5 (6) 6.5 (9) 7.5 (10)
M6
3 (4) 4 (5.5) 7.5 (10) 11 (15) 13 (18)
M8
7 (9.5) 10 (13) 18 (25) 26 (35) 33 (45)
M10
14 (19) 18 (25) 37 (50) 55 (75) 63 (85)
M12
26 (35) 33 (45) 63 (85) 97 (130) 11 (150)
M14
37 (50) 55 (75) 103 (140) 151 (205) 177 (240)
M16
59 (80) 85 (115) 159 (215) 232 (315) 273 (370)
M18
81 (110) 118 (160) 225 (305) 321 (435) 376 (510)
GENERAL INFORMATION

Polaris RZR 800 2013 Specifications

General

Brand	Polaris
Model	RZR 800 2013
Category	Offroad Vehicle
Language	English
