4.30
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
9. Remove the lower bolt retaining the seat belt
mechanism near the rear RH portion of the fuel tank.
Once removed, place the mechanism in the rear
cargo box to keep it out of the way.
10. Remove the (3) Torx fasteners from the rear RH
fender well and remove the fender well from the
vehicle (see chapter 5).
11. Remove the (3) shift lever support bracket bolts and
place the bracket out of the way of the fuel tank, but
do not remove or cut the plastic wire harness
retainer.
12. Remove the (2) tank bracket fasteners that retain the
fuel tank in the chassis. Swing the tank brackets
clear of the fuel tank for removal.
ELECTRONIC FUEL INJECTION
